Paint Crack

Figure 1 - Full-Focus Composite: This cracked paint was imaged with a 100x air objective under standard halogen lighting. Dust particles are visible within the crack. (Scroll for additional images of this sample.)


Figure 2 - Depth Colored: Depth information has been added to the image above through color with red corresponding to the higher points and blue the lower. Note the raised edges near the crack. (Scroll for additional images of this sample.)


Figure 3 - Contour Enhancement: The topography above is further enhanced through this caricature of the data. Depth has been quantized and assigned unique colors for more precise depth analysis. This type of image allows for greater assessment of the raised edges noted at the crack edges. (Scroll for additional images of this sample.)
